ACL Race Series Connecting Rod Bearing Set BMW S65

SKU: N/A Categories: ACL, BMW M3 (E90 | E92 | E93) Engine & Performance Parts, BMW M3 (E90 | E92 | E93) Parts & Accessories, BMW M3 Parts & Accessories, BMW Parts & Accessories, Brands, Engine & Performance, Engine Bearings Tags: ACL, BMW, Engine Bearlings

409.99€

Sizes

Clear

NEED HELP? CONTACT US

In Stock - Ready to Dispatch Dispatch Monday. Order in the next 2 days 55 mins.

WORLDWIDE SHIPPING

EASY RETURNS

SECURE SHOPPING

24/7 SUPPORT

WORLDWIDE SHIPPING

EASY RETURNS

SECURE SHOPPING

24/7 SUPPORT

The ACL Race Series Connecting Rod Bearing Set for BMW’s S65 engine is built for those who expect their V8 to perform flawlessly—no matter how hard it’s pushed. The 4.0-liter S65 found in the E90, E92, and E93 M3 is a masterpiece of engineering, but it’s no secret that rod bearing wear can become an issue once the revs climb and the oil temps rise. ACL’s Race Series bearings are designed to eliminate that weak point, offering the strength, consistency, and peace of mind every high-revving M3 deserves.

Each bearing is made using ACL’s trusted tri-metal construction: a hardened steel backing for rigidity, a copper-lead layer for load strength, and a precision overlay that holds a stable oil film even at high temperatures and pressures. This combination keeps friction under control and lubrication consistent, protecting your crank and rods through extended pulls, sharp shifts, and full-throttle acceleration.

The same materials used in professional motorsport engines power these bearings. They deliver exceptional fatigue resistance, precise clearances, and long-lasting oil pressure stability—crucial for the S65’s 8,400-RPM redline. The result is smoother operation, cooler running temperatures, and a stronger bottom end that can handle serious performance builds.

Installation is straightforward. ACL designed these bearings as a direct-fit replacement for BMW’s S65 engine—no machining, no modifications, just perfect OEM geometry paired with competition-grade durability.

For E9X M3 owners who demand reliability and confidence when chasing high RPMs or track times, ACL Race Series bearings are the ultimate safeguard. They reinforce the foundation of the S65, keeping it balanced, smooth, and ready to perform—lap after lap, gear after gear.

FEATURES

High-performance upgrade: ACL Race Series bearings deliver a stronger, longer-lasting replacement for BMW’s original components—engineered to withstand the extreme heat, load, and high-RPM demands of the S65 engine found in the E90, E92, and E93 M3.
Precision-engineered for BMW performance: Designed to eliminate rod bearing wear and oil pressure inconsistencies often found in the high-revving S65 V8, maintaining smooth, reliable lubrication throughout the entire rev range.
Factory-grade precision: Manufactured to exact BMW tolerances for perfect clearances, stable oil pressure, and long-term bearing life even during extended high-RPM operation or demanding track sessions.
Race-proven tri-metal construction: Built using a hardened steel backing, copper-lead intermediate layer, and precision overlay—delivering exceptional fatigue resistance, thermal stability, and consistent oil film control under load.
Optimized bearing-to-housing contact: The non-tin flash surface enhances fitment stability, minimizes distortion, and maintains precise alignment under extreme heat and prolonged stress.
Built for endurance and confidence: Proven in motorsport and high-performance builds, these bearings give the S65 the reliability it deserves—keeping your M3 running strong, balanced, and protected through every gear change and every redline run.

Acl structure

APPLICATIONS

2007–2013 BMW S65B40 E90 M3 4.0L
2007–2013 BMW S65B40 E92 M3 4.0L
2008–2013 BMW S65B40 E93 M3 4.0L

NOTES

Specifications for STD size only.

Includes upper and lower bearing shells for a complete rod bearing replacement.

ADDITIONAL INFORMATION:

Brand	ACL
Half Type	Identical halves
Material	F781
Min. Std Shaft Size	51,975 mm / 2.0463 in
Max. Std Shaft Size	51,991 mm / 2.0469 in
Min. Std Tunnel Size	56 mm / 2.2047 in
Max. Std Tunnel Size	56,013 mm / 2.2052 in
Max Wall at Crown	1,998 mm / 0.0787 in
Max Overall Length	15,9 mm / 0.6260 in
