ACL Race Series Connecting Rod Bearing Set BMW S50B30
319.99€
GET IN TOUCH
At VOGUE AUTOMOTIVE, we’re committed to making sure you’re happy with our products and services—contact us anytime for help.
In Stock - Ready to Dispatch
Dispatch today. Order in the next 2 hrs 5 mins.
The ACL Race Series Connecting Rod Bearing Set for BMW’s S50B30 engine is built for people who don’t stop at factory limits. The 3.0-liter straight-six loves to rev, but once you add power, raise compression, or stretch your sessions on track, the stock bearings can start to show weakness. ACL’s Race Series bearings are designed for exactly that—when heat, load, and precision all matter at once.
Each bearing uses ACL’s proven tri-metal construction: a hardened steel backing for strength, a copper-lead intermediate layer for load capacity, and a precision overlay that holds a steady oil film under extreme stress. That balance keeps friction low and oil pressure stable, protecting your crank and rods through every pull, corner, and full-throttle surge.
Developed using materials trusted in motorsport engines worldwide, the Race Series bearings offer excellent fatigue resistance, consistent clearances, and reliable oil control. They’re built to handle sustained high RPM, tuned boost levels, and the brutal thermal cycles that come with serious driving. The result is smooth operation, longer bearing life, and confidence when your S50B30 is running hard.
Installation is simple. These bearings drop in as a direct-fit replacement for BMW’s S50B30 engine found in the E36 M3—no machining or modification required. You get perfect factory geometry with the added durability of race-proven design.
For E36 M3 owners chasing both performance and dependability, ACL Race Series bearings are the upgrade that keeps the S50 spinning strong. They strengthen the bottom end, maintaining balance, temperature control, and reliability every time you hit redline.
FEATURES
- High-performance upgrade: ACL Race Series bearings deliver a stronger, more durable solution than BMW’s original components—engineered to withstand the heat, load, and RPM of the high-revving S50B30 found in the E36 M3.
- Precision-engineered for BMW performance: Specifically developed to address bearing wear and oil pressure fluctuations common in performance BMW engines, maintaining smooth and consistent lubrication across the entire rev range.
- Factory-level precision: Produced to exact BMW tolerances, ensuring correct clearances, reliable oil pressure, and long-term bearing stability even under demanding conditions.
- Race-proven tri-metal construction: Built with a hardened steel backing, copper-lead core, and precision overlay that together provide exceptional fatigue strength, oil film stability, and thermal control.
- Optimized bearing contact: The non-tin flash finish enhances bearing-to-housing fitment, preventing deformation and improving strength during extended high-load operation.
- Built for endurance and confidence: Proven through motorsport and high-performance applications, these bearings keep your S50 running strong and protected—on the road, on the dyno, or at full throttle on track.
APPLICATIONS
- 1992–1995 BMW S50B30 E30 M3 3.0L
NOTES
Specifications for STD size only.
Includes upper and lower bearing shells for a complete rod bearing replacement.
ADDITIONAL INFORMATION:
| Brand | |
|---|---|
| Half Type | Identical halves |
| Material | F781 |
| Min. Std Shaft Size | 49,975 mm / 1.9675 in |
| Max. Std Shaft Size | 49,991 mm / 1.9681 in |
| Min. Std Tunnel Size | 53 mm / 2.0866 in |
| Max. Std Tunnel Size | 53,015 mm / 2.0872 in |
| Max Wall at Crown | 1,48 mm / 0.0583 in |
| Max Overall Length | 18 mm / 0.7087 in |
